RWB801, Bilge Pump, Rule, 500GPH, 12v, Non-Automatic

: Unavailable

: BILGE PUMP

: RWB MARINE

Regular price $74.70

Next-generation compact submersible 500 GPH electric pump for use as a bilge or bait pump on smaller craft. Totally submersible pump with...

QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question

Category:

Tags:

Next-generation compact submersible 500 GPH electric pump for use as a bilge or bait pump on smaller craft. Totally submersible pump with water-cooled, ignition and TCO protected motor, stainless steel shaft and snap-on strainer base.
These pumps are extremely efficient, draw low current and offer a high capacity output in a very compact housing, to fit into the smallest available space.
NON-Automatic pump - requires a Rule float switch to operate automatically.
Please note - using the included check valve will reduce the output flow of the pump.
Available in both 12 volt & 24-volt models. 3-year limited warranty.

Fully submersible pump - 500 US gallons per hour - 31 liters per minute
Higher flow-optimized impeller to provide greater flow at the same amperage as the previous model
High efficiency, low amp draw, ignition protected motor includes true Electromagnetic suppression (EMC)
16 gauge tin coated copper electrical wiring with silicone infused water blocking feature to stop water wicking down inside the wiring
Built-In thermal cut-out (TCO) in the motor provides additional protection for pump & vessel
Backflow prevention - now includes a removable check valve in the discharge nozzle which
reduces the amount of water draining back from the pump discharge hose into the bilge.
Please note - using the check valve will reduce the rated output flow.
Threaded discharge port - gives easier installation and maintenance.
Discharge hose port is included with each pump
Hidden air vents in the pump prevent air locking in challenging plumbing installations and
helps with the check valve operation
Compact - 99mm Height x 74mm Width x 64mm depth - not including discharge
1.6 amp draw @ 12v DC. 0.8 amp draw @ 24v DC
Threaded hose outlet suits 20mm (3/4") hose. 1 x straight port provided.
